Tara: 11000 kg
Carga útil: 60000 kg
Longitud total: 10950 mm
Ancho total: 2500 mm
Altura total: 3620 mm
SEMIRREMOLQUE DE VOLTEO TRASERO
Tara: 11000 kg
Carga útil: 60000 kg
Longitud total: 10950 mm
Ancho total: 2500 mm
Altura total: 3620 mm
Descripción
| SPECIFICATION | ||||||
| Chassis | Heavy duty and extra durability designedI beam;opting for high tensile steel Q345,welded by automatic submerged-Arc processes.Top flange 18mm,width140mm;Middle flange 10mm;bottom flange 20mm,width 140mm | |||||
| Axle | Number | 3 | Brand | Optional upon choice | Capacity | 13T |
| Suspension | Mechanical suspension Or air suspension |  | ||||
| Leaf spring | Leaf spring or air bag | |||||
| Floor | 8mm plate side wall 6mm | |||||
| Tire | 11.00R20,12.00R20,11R22.5,12R22.5,315/80R22.5 Tire optional | |||||
| Wheel rim | 8.5-20,9.0-20,8.25-22.5,9.0-22.5 steel wheel rim optional upon choice | |||||
| Kingpin | 2“/3.5”bolt-in king pin | |||||
| Landing gear | JOST brand two-speed,manual operating,heavy duty landing gear | |||||
| Cylinder | HYVA | |||||
| Braking system | WABCO RE6 relay valer ;T30/30 spring brake chamber;40L air tanks | |||||
| Painting | Complete chassis sand blasting to clean rust,1coat of anticorrosive prime,2coats of final paint | |||||
| Accessories | One standard tool box | |||||
