Tara: 9000 kg
Volumen: 40 m³
Longitud total: 11980 mm
Ancho total: 2500 mm
Altura total: 3800 mm
REMOLQUE DE CANTIDAD DE ACEITE SMEI
Tara: 9000 kg
Volumen: 40 m³
Longitud total: 11980 mm
Ancho total: 2500 mm
Altura total: 3800 mm
Descripción
| SPECIFICATION | ||||||
| Tank body | Q235/5mm steel | |||||
| End plate | Q235A/6mm steel sheet | |||||
| Axle | Number | 3 | Brand | Optional upon choice | Capacity | 13T |
| Suspension | Mechanical suspension Or air suspension |  | ||||
| Leaf spring | Leaf spring or air bag | |||||
| Manhole cover | 500mm manhole cover.2 sets with 2 breather valve. | |||||
| Tire | 11.00R20,12.00R20,1R22.5,12R22.5,315/80R22.5 Tire optional | |||||
| Wheel rim | 8.5-20,9.0-20,8.25-22.5,9.0-22.5 steel wheel rim optional upon choice | |||||
| Discharge valve | 2-4 set of100mm discharge valves | |||||
| Discharge pipe | 4"rubber hose,2 pcs,6m Long | |||||
| Kingpin | 2"/3.5"bolt-in king pin | |||||
| Landing gear | JOST brand two-speed,manual operating,heavy duty landing gear | |||||
| Bottom valve | 1-2 sets of bottom valve | |||||
| Outside sheet | 1.2mm steel sheet | |||||
| Compartment | Optional upon choice | |||||
| Braking system | WABCO RE6 relay valer;T30/30 spring brake chamber;40Lair tanks | |||||
| Painting | Complete chassis sand blasting to clean rust,1coat of anticorrosive prime,2coats of final paint | |||||
| Accessories | One standard tool box | |||||
| Main beams | Opting for high tensile steel Q345B welded by automatic submerged-arc processes | |||||
